AM / Enduro Forks

120 - 170mm

MRP's award-winning all-mountain and enduro forks feature stout 35mm chassis, twin-tube dampers, and either the highly-adjustable FulFill™ air-spring or our high-performance coil-spring system.

Pinkbike's 2017 Suspension Product of the Year, the Ribbon (air), is the king of the 35mm class. In it's lightweight 4.15 lb. package it packs in features like Ramp Control, the FulFill™ independent positive and negative chamber air-spring system, and PSST™ pressure relief valves in the lowers. The Ribbon Coil substitutes a tunable coil spring in place of the air-spring, but otherwise has all the same features at modest weight increase.

The new Raven shares the Ribbon chassis, but has a slightly simplified damper and air-spring system. In lieu of Ramp Control, the Raven's air-spring curve can be tuned interally with our Huck Puck™ volume spacers.

TRAVEL OPTIONS:

27.5" : 120 - 170mm, 29" : 120 - 160mm

27.5" : 120 - 170mm, 29" : 120 - 160mm

27.5" : 150 - 170mm, 29" : 140 - 160mm

WHEELSIZE OPTIONS:

27.5" & 29"

27.5" & 29"

27.5" & 29"

STANCHION SIZE:

35mm

35mm

35mm

WEIGHT:

27.5" : 4.4 lbs. / 1.99 kg

29" : 4.45 lbs. / 2.02 kg

27.5" : 4.15 lbs. / 1.88 kg

29" : 4.2 lbs. / 1.9 kg

27.5" : 4.7 lbs. / 2.14 kg

29" : 4.75 lbs. / 2.16 kg

AXLE SPACING:

15x110mm (Boost)

15x110mm (Boost)

15x110mm (Boost)

EXTERNAL ADJUSTMENTS:

Air-spring pressure, 8-position compression, & rebound

Air-spring pressure, 8-position compression, Ramp Control, & rebound

Preload, 8-position compression, Ramp Control, & rebound

SPRING SYSTEM:

FulFill™ Air

FulFill™ Air w/ Ramp Control™

Coil w/ Ramp Control
